8 x 14 Guard House-PlanA-Product#: 814GHA
Pricing does not include PE Sealed Drawings or State Insignia-Quote can be provided upon request.
Included Features: 8 x 14 Guard House-PlanA
- Out swing door is positioned on the 8′ wall
- 3000 watt wall heater with fan
- 12,000 BTU through wall air conditioner with remote
- Exterior security light-LED
- Heavy duty steel base frame with built in fork pockets
- Fully insulated-walls (R-13), roof (R-30), floor (R-12, Rigid)
- Aluminum tread plate floor (over 3/4″ plywood sub floor)
- Aluminum exterior-standard colors-lite gray with dark gray-top/bottom trim
- Out swing steel door-aluminum jamb, 1/2 glass-tempered, stainless hinges, lockset, heavy duty door closer
- Tempered insulated windows (sliding & fixed), double locking, insect screen
- T-grid type ceiling with drop in LED light-wall switch
- 100 amp Main panel with (3) duplex receptacles, dedicated circuit for heat and a/c
- Counter/desktop, 24″ x 88″-laminated white
- EPDM rubber roof with 3″/6″ overhang
Click to View Drawings-8 x 14 Guard Booth-PlanA
Drawings/Plans
Shipping/Freight: Please call (856)227-0057 or email (info@guardboothonline.com) prior to your purchase for shipping rates to your specific location.
Tax: New Jersey sales tax will apply for all pickups; For shipments to NJ. and PA applicable sales tax will apply.
All other states-tax will be the responsibility of buyer.
